High Mast Poles Manufacturer in India
As the name suggests a high mast pole is a specialized structural lighting solution engineered to illuminate extensive areas with uniform daylight-like distribution from high elevations. Safety, structural stability, and wind resistance are paramount in modern infrastructure, and our continuously tapered poles deliver reliable performance across national expressways, toll plazas, industrial zones, and sports facilities.
Taravi Electricals Pvt. Ltd. is an ISO 9001:2015 certified manufacturer and leading supplier of heavy-duty polygonal high mast towers and aerodynamic octagonal street light poles. Engineered from prime high-tensile steel (IS 2062 / BS EN 10025) and hot-dip galvanized in an automated 7-tank chemical pre-treatment plant, our products guarantee 25+ years of corrosion resistance even in harsh coastal and industrial environments.
WITH TECHNICAL SPECIFICATIONS
High Mast Poles
| Description | 8 mtr | 9 mtr | 12.5 mtr | 16 mtr | 20 mtr | 30 mtr |
| Cat No. | THM 0080 | THM 0090 | THM 0125 | THM 0160 | THM 0200 | THM 0300 |
| Material Construction | IS 2062 Grade E250 / E350 | IS 2062 Grade E250 / E350 | BSEN 10025 / IS 2062 | BSEN 10025 / IS 2062 | BSEN 10025 / IS 2062 | BSEN 10025 / IS 2062 |
| No. of Longitudinal Welds | Single Longitudinal (AWS D1.1) | Single Longitudinal (AWS D1.1) | Single Longitudinal (AWS D1.1) | Single Longitudinal (AWS D1.1) | Single Longitudinal (AWS D1.1) | Single Longitudinal (AWS D1.1) |
| Cross Section of Mast in Polygon (No. of Sides) | Polygonal / Octagonal | Polygonal / Octagonal | 12 / 16 Polygon | 16 / 20 Polygon | 20 Polygon | 20 Polygon |
| No. of Sections | 1 Single Section | 1 Single Section | 2 Slip-Joint | 2 Slip-Joint | 2 Slip-Joint | 3 Slip-Joint |
| Thickness | 3 MM | 3 MM | 4, 3 MM | 3, 3 MM | 4 MM | 4, 4, 3 MM |
| Individual Section's Length | 8000 MM | 9000 MM | 6500 MM | 8300 MM | 10500 MM | 10500 MM |
| Top / Bottom Diameter (OD) | 70 MM / 155 MM | 70 MM / 155 MM | 150 MM / 310 MM | 150 MM / 360 MM | 150 MM / 460 MM | 150 MM / 540 MM |
| Base Plate Dimensions | 220 x 220 x 12 MM | 260 x 260 x 16 MM | Dia 510 x 20 MM | Dia 520 x 25 MM | Dia 670 x 25 MM | Dia 630 / 730 x 32 MM |
| Foundation Anchor Bolts | 4 Nos. M20 x 650 MM | 4 Nos. M20 x 650 MM | 6 Nos. M24 x 750 MM | 8 Nos. M30 x 850 MM | 8 Nos. M24 x 750 MM | 12 Nos. M30 x 850 MM |
| Drum's & Winch Type | Fixed Head Assembly | Fixed Head Assembly | 2 Nos. Self-Sustaining | 2 Nos. Self-Sustaining | 2 Nos. Self-Sustaining | 2 Nos. Self-Sustaining |
| Safe Working Capacity (SWL) | Standard Array | Standard Array | 350 - 500 Kg (Up to 6 Lights) | 750 Kg (Up to 8 Lights) | 750 Kg (Up to 10 Lights) | 750 - 1000 Kg (Up to 16 Lights) |
| Number of Ropes / Thickness | N/A | N/A | 3 Nos. / 5mm SS 316 | 3 Nos. / 6mm SS 316 | 3 Nos. / 6mm SS 316 | 3 Nos. / 6mm SS 316 |
| Power Tool / Motor Capacity | NIL (Fixed Head) | NIL (Fixed Head) | 1.0 HP Reversible | 1.5 HP Reversible | 1.5 HP Reversible | 2.0 HP Reversible |
Download / View Catalog
We take pride in our ability to provide custom design builds that are easy to use, robust, and durable. Our in-house engineering team uses STAAD.Pro structural stability calculations to design products for challenging & demanding environmental wind zones up to 180 km/h. Our CNC-based automated manufacturing unit located in Ramnagar Industrial Area, Varanasi ensures precision in tandem bending and longitudinal submerged arc welding. We use prime materials conforming to IS 2062 to guarantee reliability. Our numerous approvals from UP PWD, CPWD, NHAI, and state government authorities validate our unyielding commitment to engineering excellence.
High Mast Pole Technical Features
Fixed Type Head Frame: The non-corrosive aluminum pulley system is designed with a larger diameter to provide a longer life and perfect balancing of the lantern ring carriage.
Winches: The winch is designed with a gear ratio of 53:1 and without breaks or clutches. These are self-lubricated for sustained, trouble-free life. We provide winches made of treated bronze, which adds to their lifespan and ensures trouble-free service.
High Mast Finish: For a longer lifespan, the mast and all of its components receive an anti-rust treatment and a fully hot galvanized treatment as per IS 4759 / BS EN ISO 1461.
Lantern Carriage: We specialize in custom-built designs, standard lighting designs, and numerous types and shapes. The lantern carriage is supported by flexible 6/8 sq.mm. S.S. wire ropes from the distributors, which can be elevated or lowered electrically as well as mechanically.
TARAVI ELECTRICALS PVT. LTD.
Top Section of High Mast Pole
- Lighting arrestor
- Hoist & supply cable pulleys
- Head assembly
- Canopy fixing bracket
- Sleeve pipe
- SS Wire rope (AISI 316)
- Terminal Box
- Bracket Carrying Lights
- Supply cable
Bottom Section of High Mast Pole
- Compensating pulley
- Supply cable clipped to compensating pulley
- Winch mounting plate
- Door cover with tamper-proof lock
- Double drum self-sustaining winch (53:1 ratio)
- Gusset plate stiffeners
- Heavy base plate & foundation anchor bolts
